T2^® / T2-HP^™

LIGHTWEIGHT YET DURABLE, COMPACT YET POWERFUL.

Lightweight yet durable, compact yet powerful. The T2® features rugged, die-cast aluminum housings and a sturdy ¾” axle that ensures top performance year after year. Its infinite speed control delivers precise handling even in the tightest spots. And the maintenance-free design means you’ll spend less time working and more time doing whatever you want.

• Sturdy 3/4 in axle
• Infinite speed control for precise handling
• Maintenance-free design for ease of use

SPECIFICATIONS

• OVERALL TRANSAXLE REDUCTION
  • Model T2 - 22.68:1
  • Model T2-HP - 25.42:1

• INPUT SPEEDS

• MAXIMUM HI-IDLE (NO LOAD) - 3000 rpm
• MINIMUM (LOADED) - 1800 rpm

• OUTPUT TORQUE – CONTINUOUS
  • Model T2 - 115 lb-ft [156 Nm]
  • Model T2-HP - 215 lb-ft [291 Nm]

• OUTPUT TORQUE - INTERMITTENT
  • Model T2 - 145 lb-ft [197 Nm]
  • Model T2-HP - 285 lb-ft [386 Nm]

• AXLE SHAFT DIAMETER - 0.75 in [19.05 mm]

• AXLE SHAFT END OPTIONS - Keyed or DD

• PARKING BRAKE TYPE - External Disc

• WEIGHT OF UNIT - 28 lb [12.7 kg]
